Replacement Touch Screen Digitizer forNOBKLEN J11 (Model: JR-J11) Kids Android 10 Inch Tablet PC

There are many versions of touch screen panels, please open (take apart) the tablet back cover to check, if you buy a wrong item, there is no free replacement and full refund.

How to choose a correct touch screen:

• 1. Check the dimension of touch panel (width and height in mm), and the camera hole position/distance (left board to camera hole).
  Example:
•
• 2. Check the type of the touch screen ribbon cable (Type-X: Cross Flex Cable; Type-Y: Parallel Flex Cable).
• Type-X: Cross Flex Cable
• Type-Y: Parallel Flex Cable
•
• 3. Check the number of channels (X axis and Y axis).
  Example:
•
• --------------------------------------------------------------------------
• -------------------Model List---------------------------------------
•
• Model-1: Type-Y Parallel Flex Cable; 50 Pins; Number of Channels: 26*14 Pins or 26*13 Pins; Camera Position: 109mm; Dimension: 237*167mm
• Model-2: Type-Y Parallel Flex Cable; 50 Pins; Number of Channels: 26*14 Pins or 26*13 Pins; Camera Position: 118mm; Dimension: 237*167mm
•
•
• Model-3: Type-X Cross Flex Cable; 50 Pins; Number of Channels: 26*14 Pins or 26*13 Pins; Camera Position: 109mm; Dimension: 237*167mm
• Model-4: Type-X Cross Flex Cable; 50 Pins; Number of Channels: 26*14 Pins or 26*13 Pins; Camera Position: 118mm; Dimension: 237*167mm
•
•
• Model-5: Type-X Cross Flex Cable; 50 Pins; Number of Channels: 28*18 Pins; Camera Position: 109mm; Dimension: 237*167mm
• Model-6: Type-X Cross Flex Cable; 50 Pins; Number of Channels: 28*18 Pins; Camera Position: 118mm; Dimension: 237*167mm
•
•
• Model-7: Type-Y Parallel Flex Cables; 50 Pins; Number of Channels: 26*14 Pins; Camera Position: 118mm; Dimension: 237*164mm
• Model-8: Type-X Cross Flex Cable; 50 Pins; Number of Channels: 26*14 Pins; Camera Position: 118mm; Dimension: 237*164mm
•
•
• Model-9: Type-Y Parallel Flex Cables; 50 Pins; Number of Channels: 26*14 Pins; Camera Position: 119mm; Dimension: 238*167mm 2.5D
• Model-10: Type-X Cross Flex Cable; 50 Pins; Number of Channels: 26*14 Pins; Camera Position: 119mm; Dimension: 238*167mm 2.5D
•
• Others: If your touch screen is not in the above list. Please email (add photos to the attachment) to us, or tell us the text on the touch screen flex cable. And then we will check and send you correct touch screen.

Warning:

• 1. Double confirm your tablet PC model, touch screen dimension, cable size and camera hole/button position before buying. We do not supply free replacement, if you buy the wrong item.
• 2. Professional skills required for replacing the touch screen, we are not responsible for any of your wrong operation.
• 3. Do NOT install the touch screen in your machine before testing.
• 4. Item should be same as we ship out if you need exchanging or replacing service, glue, dirt and scratch not acceptable.
• 5. This is a fragile item, negative feedback unacceptable if the item damaged on arrival, kindly contact us first for sending a replacement.
• 6. If you are not sure, you had better open the back cover of the tablet and take photos to us, we can help you find the right one.
• 7. This is free shipping with tracking number, so we choose the better shipping service. Also you can choose faster EMS/DHL service.

Above provision takes effect once you place an order.
